BODY
Dynacorn 69/70 Mustang body
or A47 Supplied 69/70 original Mustang Body
or Customer supplied 69/70 original Mustang Body
Body blasting and transport to/from
Extensive body lightening
Seam welding
Carbon flared rear fenders
A47 lightweight urethane headlight buckets stock style
or A47 lightweight urethane headlight buckets with aero covers
A47 lightweight urethane rear quarter end caps
or A47 Lightweight urethane rear quarter end caps for wing
A47 fiberglass front spoiler and gravel shield
or A47 Racing front Aero package
(Fascia, Tegris splitter, bumper frame and stantions)
Front and rear bumpers steel
or Front and rear bumpers carbon
Stock front grill
A47 Ram air scoops
Maier stock style composite hood
or Ducted Hood Package including
Ducted hood
Wizard tilt radiator
Aluminum duct assembly
Aerocatch hood pins
Hood props
Electric pusher fans
Brake cooling package
A47 cooling scoops
Duct
Spindle brackets
69 rear taillight panel grafted to 70 body (69 boss 302 style)
A47 lightweight tail light housings
Stock tail light gaskets
Stock 69 tail light lenses
or A47 Tinted tail light lenses
Scott Drake sequential LED tail lights
Drip rail shaving
G-stream rear wing with custom stantions and in trunk supports
Flush mount scratch resist Lexan front windshield
or New stock glass front windshield
Flush mount scratch resistant rear glass with supports
or Stock glass rear glass installed (usually breaks on removal)
Firewall smoothing
Anvil composite decklid
Stock decklid hinge spring delete
Rear decklid prop
Aluminum transmission tunnel cover
(needed for most aftermarket transmissions)
A47 Tow hooks front and rear
Tie down loops rear
Front jack stand/tie down points
Body panel alignment
Paint interior and exterior (race quality)
or Paint interior and exterior (street quality)
ENGINE
Coyote Power
Ford Coyote 5.0L motor
or Ford Racing Coyote 5.0L Aluminator N/A
or Ford Racing 5.0L Aluminator XS Crate Engine
Controls Pack, 5.0L 4V Crate Motor
Serpentine belts
Turnkey Boss fuel system
Ford Racing Mustang Boss 302 Alternator Kit (11-13 GT)
A47 alternator relocate bracket
Lightweight Coyote Starter
Spring tower delete for mod motor
Power steering and acc. drive
A47 EFI ram airbox w/ filter, intake hose, brackets
AIM Evo 4 data acquisition
Pushrod Power
Roush pushrod 331 turnkey ready
Customer spec'd motor
MSD ignition
Throttle pedal assembly
A47 Trans Am ram air box and KN filter
SCT tuner
Chassis dyno tuning
POWERTRAIN
Ford T-56 Magnum close ratio 6 Speed Transmission
Quicktime bell housing
Exedy clutch and flywheel
or McCleod RST clutch and flywheel
McCleod 1400-30 Hydraulic throwout bearing
Moser third member and Wavetrac rear diff
or Third member with spool
Aluminum drive shaft
SUSPENSION
A47 Front SLA suspension with SN-95 rack and pinion steering
A47 Rear 3 Link rear suspension including speedway housing and watts link
or A47 Rear V-Link rear suspension including speedway housing and watts link
JRi non adjustable coilover shocks with A47 tune
or JRi single adjustable coilovers
or JRi double adjustable coilovers
A47 Front sway bar and end links
Rear sway bar and end links
BRAKES
Wilwood 6 piston, 14" caliper front and 4 piston rear
or Baer Extreme+ 6 piston, 14" caliper front and rear
Hawk DTC 70 Racing pads
or Customer spec'd pads
WHEELS
Forgeline/Agent 47 18" Minilites in 9.5 or 11" width
or Forgeline 18" GA3R in 9.5 or 11" width
or Customer spec'd wheels
(In the appropriate size and backspace)
TIRES
Toyo RA1
Nitto NT-01
BFG G-Force Rivals
(Widths from 275 to 315 in 18")
INTERIOR
12 point cage
Weld in door bars Nascar style
or Bolt in Nascar door bars
Weld in door bars "X" style (passenger side)
Weld in diagonal bar
or Bolt in diagonal
Roll bar padding + leather wrap
A47 quick release window net
Racing seat options
ISP full containment race seat
Kirkey full containment race seat
A47 vintage racing seats package
Customer spec'd seat
Racing harness options
Crow 6 point Latch link harness
Schroth clubman Harness
Schroth Profi II Harness
Schroth Enduro Harness
Seat delete assembly (required for side exit exhaust)
Pedal package
Tilton Hanging Pedals
A47 Pedal Pads
Mounting brackets
Tilton brake and clutch reservoir and mount
Tilton master cylinders
Composite raised floor pan (heat shield)
Dash and gauge package
Scott Drake dash with trimming, mounting tabs and extension plate
or Trimming of existing dash
A47 gauge panel with location for fire pul and master switch
Stewart warner gauges
Speedo cable Lokar and recalibration gear
Agent 47 carbon FDM shifter
or Joes Shift lever setback w/ tremec knob
Sweet steering column package
Steering wheel quick release
Mounting brackets
Momo Mod 80 steering Wheel
Steering column, shafts and U-joints
Frame support plate w/ rod end
Firewall bearing and plate
Master switch with battery cable (with A47 gauge panel)
Brake bias, Warning Light package
Aluminum interior skins w/ rear panel
Rear quarter glass deletes
A47 lightweight Interior door panels
A47 center console switch panel w/ Starter button
Fuel Safe Pro 22 fuel Cell Package
Locking Newton Gas cap with filler hose
Battery tray trunk mounted
Removable carpet
BADGING
3D printed stainless steel serialized number plate
Harbinger floor mats
Harbinger rear badge
Harbinger fob for ISIS system
ELECTRICAL
Isis Multiplex lightweight electrical system
PLUMBING
Remote oil filter
Setrab oil cooler
A47 custom radiator hoses
Accusump kit
A47 fuel pump bracket
A47 headers ceramic coated w/ locking hardware
Side exit exhaust package
Stainless tip plate
Custom exhaust system
Electric dump valves and turn downs
Heat shielding and pipe wrap
or Exhaust system T/A style exit with Magnaflow mufflers
FIRE SYSTEM
Fire bottle RC-500 fire system
or Fire bottle AMRC-1000 fire system
